| Weight (kg) | 3,8 |
|---|---|
| Length (mm) | 455 |
| Width (mm) | 274 |
| Cover length (cm) | 39,3 |
| Cover width (cm) | 23,5 |
| Consuption per m2 | 10.8 |
| Pieces on a pallet/pallet weight(pcs/kg) | 280/1120-1140 |
| Minimum roof slope, degrees | 15° |
| Slat spacing (cm) | 36-38 |
ROOF COVERING DETAIL
Conditions for a roof slope from 20° to 45°.
Compliance with all recommended technical requirements for substructure installation, which implies:
→ Roof membrane Climateq PRO 120 weight 120 g/m2 multi-layer membrane: – lower side vapor permeable – upper side waterproof
→ Placing the foil – parallel to the eaves
→ Folds 10 – 15 cm
→ A sealing strip is placed under the counter batten
→ Safety measures – ladder for walking on the roof
